insulate glass 6+12A+6

    Buy cheap insulate glass 6+12A+6 from wholesalers

    Buy cheap insulate glass 6+12A+6 from wholesalers
    • Buy cheap insulate glass 6+12A+6 from wholesalers

    insulate glass 6+12A+6

    Ask Lasest Price
    Brand Name : Sun Global Glass
    Certification : BS6026, SGS ,ISO, CE...
    Model Number : insulated glass
    Price : USD1-USD19.9
    Delivery Time : 7-10 day after deposit received
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, Other
    Supply Ability : 3200 Tons per Week
    • Product Details
    • Company Profile

    insulate glass 6+12A+6

    Quick Details

    • Place of Origin: Guangdong, China (Mainland)
    • Brand Name: SGG
    • Model Number: insulate glass
    • Function: Bulletproof Glass, Heat Absorbing Glass, Heat Reflective Glass
    • Shape: Flat
    • Structure: Solid
    • Technique: Laminated Glass, Tempered Glass
    • Type: Float Glass
    • Thickness: 3mm,4mm,5mm,6mm,8mm,10mm,12mm,15mm,19mm
    • Color: Clear, bronze, grey, green, blue
    • Size: Min. 200x300mm, Max.2440mmx8000mm, custom sizes
    • Deep proessing: Laminated, insulated, acid etched, printed
    • Applications: Windows, doors, curtain wall, balcony, railling, table top
    • Certificate: CE, ISO, CCC, BS6202

    Packaging & Delivery

    Packaging Details:Exportation plywood crates
    Delivery Detail:7-10 day after deposit

    insulate glass 6+12A+6


    Specification

    Insulating glass units, or IGUs, are designed to keep homes warmer in the winter and cooler in the summer.

    An insulating glass unit commonly consists of two (sometimes more) panes of glass separated by a spacer material and sealed together at the edge. The insulating airspace is filled with air or a noble gas, such as argon or krypton inside. Each glass pane has two surfaces, so typical double-paned IGUs have four surfaces.

    Combined with a low-e glass coating, these gases work to improve the window’s overall u-value, which is a measure of the heat transmission through a building part (such as a wall or window). The lower the u-value, the better the insulating glass unit.

    The most common configuration of IG units for commercial building is a 6 mm lite, 12mm of air space and a 6mm lite.

    Glass thickness3mm,4mm,5mm,6mm,8mm,10mm,12mm,15mm,19mm
    Spacer thickness

    6A, 9A, 12A, 15A, 20A

    Glass Tyep

    float glass, tempered glas, laminated glass, low-E glass, tinted glass

    Glass colorClear, bronze, grey, green, blue, etc.
    Spacer typeAir, vacuum, argon
    SizeMax: 2700x3700mm, Min:180x350mm custom sizes
    Glass compositionFloat glass, laminated glass, tempered glass, Low-E glass
    ApplicationsWindows, doors, curtain wall
    CertificateCE, ISO, CCC, BS6202
    PackingExportation wood box
    Delivery time7-15 days

    Product Picture


    insulate glass 6+12A+6


    Glass Type


    insulate glass 6+12A+6


    Applications


    insulate glass 6+12A+6


    Production


    insulate glass 6+12A+6


    Packing & Loading


    insulate glass 6+12A+6

    Certification


    insulate glass 6+12A+6


    SUN GLOBAL GLASS Advantages

    a. 22 years experiences on glass manufacturing and exporting.

    b. Advanced glass machines and tecnology

    c. Excelente quality with very competitve price

    d. Export to more 75 countries in the world.

    e. Customize all kinds of glass products for each cliente

    f. Safety package and fast delivery

    g.Professional services for maximizing customer benefit
